FORD M-151
Mutt
1959 - 1988
A.K.A. Military Utility Tactical Truck
ASSEMBLY: Detroit, MI, USA
UNITS PRODUCED: > 100,000
The M-151 Mutt was the successor to the Willys M38-A1, and was the first military jeep to feature an integrated body design and coil suspension. It was designed and initially produced by Ford Motors, but subsequent contracts were also granted to Kaiser and AMC. As such, its distinctive grille features horizontal slots because Jeep retained the copyright to the vertical-slot design of previous military jeeps. The M-151 enjoyed a production run longer than all previous military jeeps combined, with over 100,000 units produced between 1959 and 1988.
FORD M-151 Mutt SPECS
MAIN SPECS
OVERALL LENGTH (OL): 132.7
OVERALL WIDTH (OW): 64.3
OVERALL HEIGHT (OH), CANVAS TOP: 71.0
OVERALL HEIGHT (OH), NO TOP: 69.5
OVERALL HEIGHT (OH), FRAME: 53.8
WHEELBASE (WB): 85.0
TRACK WIDTH (TR): 53.0
CURB WEIGHT (CW): 2,400 lbs
WINDSHIELD ANGLE (WA): 15°
CHASSIS SPECS
GROUND CLEARANCE (GC): 10.2
APPROACH ANGLE (AA): 56°
BREAKOVER ANGLE (BA): 28°
DEPARTURE ANGLE (DA): 44°
SUSPENSION TYPE (SU): Coil Spring
WHEEL SPECS
WHEEL NAME: Combat Wheel
WHEEL DIAMETER (WD): 16.0
WHEEL WIDTH (WW): 4.5
BOLT PATTERN (BP): 5 x 5.5
TIRE WIDTH (TW): 6.5
TIRE DIAMETER (TD): 28.5
SPARE LOCATION: Rear Spare
All specifications refer to original stock versions
All dimensions shown in inches
Drawn by Christopher James Botham
