JEEP SJ SUPER WAGONEER
1966 - 1968
ASSEMBLY: Toledo, OH, USA
UNITS PRODUCED: 1,475
PREDECESSOR: SJ Wagoneer
SUCCESSOR: SJ Grand Wagoneer
The SJ Super Wagoneer shares a front end with the J-4000 Gladiator, and it succeeded the SJ Wagoneer. It was an upgraded trim package for the standard Wagoneer, and it was only offered for 3 years. Sales were low, and only 1,475 Super Wagoneers were made.
WILLYS MB SPECS
MAIN SPECS
OVERALL LENGTH (OL): 186.5
OVERALL WIDTH (OW): 76.0
OVERALL HEIGHT (OH): 66.3
WHEELBASE (WB): 110.0
TRACK WIDTH (TR): 58.0
CURB WEIGHT (CW): 4,350 lbs
CHASSIS SPECS
GROUND CLEARANCE (GC): 8.5
APPROACH ANGLE (AA): 33°
BREAKOVER ANGLE (BA): 18°
DEPARTURE ANGLE (DA): 17°
SUSPENSION TYPE (SU): Leaf Spring Suspension
WHEEL SPECS
WHEEL NAME: Super Wagoneer Wheel
WHEEL DIAMETER (WD): 16.0
WHEEL WIDTH (WW): 6.0
BOLT PATTERN (BP): 5 x 5.5
TIRE WIDTH (TW): 7.0
TIRE DIAMETER (TD): 27.5
SPARE LOCATION: Spare in Trunk
All specifications refer to original stock versions
All dimensions shown in inches
Drawn by Christopher James Botham
